Forged Pistons for Ford 2.3L Eco Boost, 88mm, 9.5:1 (CP Pistons SC7544)
For shipping cost -add all the products you would like, then navigate to the shopping cart to calculate shipping quote.
|
Make |
Ford |
|
Model |
2.3L Eco Boost |
|
Part Number |
SC7544 |
|
Cylinders |
4 |
|
Bore (in) |
3.4645 |
|
Bore (mm) |
88 |
|
Size |
+0.5mm |
|
Stroke |
94 |
|
Conrod |
149.3 |
|
Comp Height (in) |
1.292 |
|
Comp Height (mm) |
32.8 |
|
Dom/Dish CC |
-6.89 |
|
Compression Ratio |
9.5 |
|
Weight (Grams) |
357 |
|
Pin (mm) |
22.5 |
|
Rings |
CPN-3445 |
|
Ring Thickness |
1.0 x 1.2 x 2.8mm |
|
Pin included (Standard) |
886-2250-16CP1C |
|
Upgraded Pin |
|
|
Ultra Duty Pin |
|
|
Locks |
886X063 SWL |
CP pistons are compatible with oversized valves and high lift camshafts. CP Pistons represent the highest quality and is engineered for maximum power. Standard features include: Deep valve reliefs accommodate high lift camshafts; Larger valve reliefs for +1mm valve sizes; Custom skirt cam and barrel design; Accumulator grooves; High strength aluminum forgings; High performance rings; Fully CNC machined and balanced to +/- 1 gram; Wrist pins included at no additional cost; Double pin oilers force fed from oil ring groove; Pin lock grooves for easy lock removal; Pin fitting included.
| Product Name | Forged Pistons for Ford 2.3L Eco Boost, 88mm, 9.5:1 (CP Pistons SC7544) |
|---|---|
| Brands | CP Carrillo |
| Make | Ford |
Delivery & Freight
We are an Australian-based company that ships items nationally and internationally, usually within 48 hours of receiving your order. High-value items shipped internationally are sent via DHL Express, while lower-value items are sent via Australia Post Express unless otherwise instructed.
You can calculate shipping rates inside the shopping cart. After adding all the products you would like, navigate to the cart and click the ESTIMATE SHIPPING & TAX link. .
If you only see the Click and Collect shipping option, it means that your address was not validated correctly.
If you have issues calculating freight, please get in touch. We are happy to help.
If you are outside of Australia, you are responsible for any duty or taxes charged by your government."
Disclaimer:
Product images are for description purposes only. Actual product may vary.
Shipping calculations available at checkout.
If you are unsure, get in touch by emailing [email protected], messaging us on Facebook, or phoning us at +61 7 5645 1333 (8am to 2pm AET).
What information do I need to match these pistons to my engine?
You need the engine code, bore size, stroke, rod length, pin diameter and target compression ratio. These determine the correct piston compression height and crown design.
How should ring gaps be set for these pistons?
Ring gaps must be set by your engine builder based on fuel type, boost level and the intended rpm range. Forced-induction engines usually require larger gaps.
Are forged pistons suitable for street engines?
Yes. Forged pistons handle detonation and high cylinder pressure better than cast units. Your builder should set the piston-to-bore clearance to suit your application.
What is the recommended compression ratio for the SC7544 pistons?
The SC7544 pistons have a compression ratio of 9.5:1, which is suitable for performance applications in the Ford 2.3L Eco Boost engine. Ensure that your engine's setup, including fuel quality and tuning, is compatible with this compression ratio for optimal performance.
What is the weight of the SC7544 pistons?
Each SC7544 piston weighs 357 grams. This weight is designed to provide a balance between performance and reliability, making them suitable for high-performance builds.
What type of wrist pins are included with the SC7544 pistons?
The SC7544 pistons come with standard wrist pins, part number 886-2250-16CP1C, included at no additional cost. Ensure proper fitting and lubrication during installation for best performance.
Are the SC7544 pistons compatible with high lift camshafts?
Yes, the SC7544 pistons feature deep valve reliefs that accommodate high lift camshafts, making them suitable for performance applications where increased airflow is desired.
What machining considerations should I keep in mind when using the SC7544 pistons?
When installing the SC7544 pistons, it's crucial to ensure correct bore clearance and ring gaps as specified by your engine build. Additionally, the pistons should be fully balanced with the rotating assembly to maintain reliability at high RPMs.
